Typical inductive sensors 回概述

IKT 5 - standard switching distance

产品形式：

Order code:

IKT 5-S-B2-PSL-KM3

序号：

996-01039

简短的说明：

Inductive sensor 5 x 5 / cubic housing

问题有关的产品

描述

Various parameterization options
IO-Link 1.1

产品的数据

Rated operating distance Sn [mm]

1.5

Repeatability [mm]

0.03

Interface

IO-Link

Velocity [Hz]

≤ 3000

Mounting

Flush

Housing

Brass, chrome-pated

Series

5x5

Type

Cubic

Switching output

PNP

Temperature range [°C]

-25 ... +70

Connection type

Pigtail, plug M8, 3-wire, 200 mm

Enclosure rating

IP 67

下载

Inductive Sensors - the metal detectors pdf, 664.42 KB

11 Inductive sensors Catalog (pdf, 7.90 MB)

IKT 5 Technical data sheet (pdf, 326.77 KB)

IKT 5-S-B2-PSL-KM3 CAD (zip, 200.81 KB)

IKT-5-S-B2-PSL-KM3 IODD (zip, 760.68 KB)

IKT 5-S-B2-PSL-KM3 IO-Link data sheet (pdf, 258.19 KB)

附件

SensoTune

Software tool for parametrization of sensors and for visualization of process data over time

SensoIO

Service tool for parameterization of sensors with IO-Link
